£172.99
Most items are in stock at our Lewisham shop. Anything not on the shelf is sourced within 5–7 working days. Call 020 8037 0653 to check before you travel.
| CPU | AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors * Refer to CPU support list. |
|---|---|
| Chipset | AMD B850 Chipset |
| Memory | 4 x DIMM slots, max. 256GB, DDR5 Supports up to 8000+MT/s (OC) Dual channel memory architecture Supports AMD EXPO™, ASUS AEMP * ECC/Non-ECC un-buffered DIMM support varies. See CPU/Memory Support list. * DDR5 memory supports On-Die ECC. |
| Graphics | 2 x DisplayPort (up to 8K@30Hz) 1 x HDMI™ (up to 4K@60Hz) * Graphics vary based on CPU. |
| Expansion Slots | Ryzen 9000/7000: 1 x PCIe 5.0 x16 Ryzen 8000: 1 x PCIe 4.0 x16 (x8/x4) Chipset: 1 x PCIe 4.0 x16 (x1) * See PCIe bifurcation table. |
| Storage | 3 x M.2, 4 x SATA 6Gb/s Ryzen 9000/7000: M.2_1 (PCIe 5.0 x4), M.2_2 (PCIe 4.0 x4) Ryzen 8000: M.2_1 (PCIe 4.0 x4), M.2_2 (PCIe 4.0 x4/x2) Chipset: M.2_3 (PCIe 4.0 x4) RAID support varies: – 9000: RAID 0/1/5/10 – 8000: RAID 0/1 – 7000: RAID 0/1/10 |
| Ethernet | 1 x Realtek 2.5Gb Ethernet, ASUS LANGuard |
| Wireless & Bluetooth | Wi-Fi 6E (2×2, 802.11ax, 2.4/5/6GHz) Bluetooth® v5.4 * Wi-Fi 6E supported on Windows 11 or later. |
| USB | Rear (8): 2 x USB 10Gbps (Type-A), 2 x USB 5Gbps (Type-A), 4 x USB 2.0 (Type-A) Front (7): 1 x USB 5Gbps Type-C®, 1 x USB 5Gbps header (2 ports), 2 x USB 2.0 headers (4 ports) * USB-C® max power: 5V/3A |
| Audio | Realtek 7.1 Surround Sound HD Audio CODEC – Jack-detection, Multi-streaming, Front Panel Jack-retasking – Up to 24-Bit/192kHz playback Features: Audio Shielding, Premium capacitors, Dedicated PCB layers * HD audio chassis required for 7.1 support |
| Back Panel I/O | 2 x USB 10Gbps (Type-A) 2 x USB 5Gbps (Type-A) 4 x USB 2.0 (Type-A) 2 x DisplayPort, 1 x HDMI™ 1 x Wi-Fi module 1 x 2.5Gb Ethernet 3 x Audio jacks 1 x BIOS FlashBack™ button |
| Internal I/O | Cooling: 1 x CPU Fan, 1 x CPU OPT, 1 x AIO Pump, 3 x Chassis Fans Power: 1 x 24-pin, 1 x 8-pin +12V, 1 x 4-pin +12V USB: 1 x USB-C®, 1 x USB 5Gbps header, 2 x USB 2.0 headers Misc: 3 x ARGB Gen 2, Clear CMOS, COM Port, Front Audio, S/PDIF Out, SPI TPM, System Panel |
| Special Features | ASUS 5X PROTECTION III: DIGI+ VRM, LANGuard, Overvoltage, SafeSlot, Steel I/O Q-Design: Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED, Q-Slot Thermal: M.2 + VRM heatsinks EZ DIY: BIOS FlashBack™, LED, Pre-mounted I/O Aura Sync: 3 x ARGB Gen 2 headers |
| Software | Armoury Crate: Aura Creator, Sync, Fan Xpert 2+, Power Saving ASUS AI Advisor, Driver Hub, GlideX, TurboV Core, CPU-Z Trials: Adobe Creative Cloud, Norton 360 (60 Days), WinRAR (40 Days) UEFI BIOS: EZ Mode, MyHotkey, CrashFree, EZ Flash |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | Cables: 2 x SATA Misc: WiFi Q-Antenna, M.2 rubber & screw packages Docs: Quick start guide |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Form Factor | mATX (24.4 cm x 24.4 cm / 9.6″ x 9.6″) |
| Form Factor | |
| Motherboard formfactor | Micro-ATX |
| Wi-Fi & LAN | |
| LAN | Yes |
| LAN Ports | 1x 2.5 Gbit/s |
| Wi-Fi / Bluetooth | Yes |
| Colour | |
| Primary Colour | Black |
| Lighting | |
| Lighting / RGB | Yes |
| Motherboard | |
| Motherboard Chipset | AMD B850 |
| CPU | |
| CPU Manufacturer | AMD |
| CPU Socket | AM5 |
| Fan Header | |
| 4 Pin Fan Connectors | 6 |
| Memory | |
| Max. Memory | 256 GB |
| Memory Type | DDR5 |
| Memory Form Factor | DIMM |
| Memory slots | 4x |
| Internal Ports | |
| CPU Power Supply | 1x 4-Pin + 1x 8-Pin |
